Stage led screen-ShenZhen Megagem Tech Co.,Ltd

< >

Stage led screen

Rental & Events	MIR-2.97	MIR-3.91	MIR-4.81
Pixel Pitch (mm)	2.97	3.91	4.81
Pixel Density (dot/㎡ )	113,569	65,536	43,264
LED Type	SMD2121	SMD2121	SMD2121
Module Size (W x H x D)mm	250x250x15	250x250x15	250x250x15
Module Resolution (W x H)	84x84	64x64	52x52
Module Weight (Kg)	0.61	0.60	0.60
Power Consumption per Module (W)	40	40	40
Driver Mode (Scan)	1/16	1/16	1/13
Brightness (cd/㎡ )	≥1,000	≥1,000	≥1,000
Grey Scale (bits)	14	14	14
Refresh Rate (Hz)	≥1,920	≥1,920	≥1,920
Cabinet Size (W x H x D)mm	500x500x92	500x500x92	500x500x92
Cabinet Resolution (W x H)	168x168	128x128	104x104
Cabinet Weight (Kg/cabinet )	8.2	8.2	8.2
Max Power Consumption (W/㎡ )	≤700	≤700	≤700
Average Power consumption (W/㎡ )	250	250	250
View Angle (Hº/Vº)	120/120	120/120	120/120
Mini View Distance (m)	3	4	5
Operating Use Temperature (℃)	-10℃~40℃
Storage Use Temperature (℃)	-20℃~50 ℃
Input Voltage (V)	100~240V
Input Power Frequency (Hz)	50Hz-60Hz
Failure Rate	<1/100,000
Signal Input Format	SDI, RGBHV, YUV,YC, Composite, HDMI,DVI, SD/HD-SDI etc.
Life Time (hrs)	100,000
